Product overview:
TWG-32 Round tube bending machine is one of major product of round tube processing equipments developped by our factory. The operation of this machine has manual operation and automatic operation two types It can bend round tube and square tube(thickness under 1~2.5mm) into arc shape(≤180°) .This equipment looks novel and distinctive,it’s necessary equipment in the fields of wrought iron steel furniture and architectural tube processing.
Technical parameters and machining capacity:
NO |
Items |
TWG-32 Capacities |
1 |
Max size of the stocks to be processed |
Round tube |
φ32 |
Square tube |
20×20 |
Flat tube |
30×8 |
2 |
Thickness of tubes |
≤1.2~2.5 |
3 |
Arc Capacity |
≤180° |
4 |
Motor |
Power |
0.4kw |
Voltage |
380V 50HZ |
5 |
External size(mm) |
800×500×1180(mm) |
6 |
Packing size(mm) |
920×680×1170(mm) |
7 |
Net Weight(kg) |
347/390kg |
